Description

Camera
Image Sensor	1/3″ CMOS
Lens	2.8mm horizontal field of view: 107° , 3.6mm horizontal field of view: 72.3°
Iris	Fixed iris
Angle of View (H)	107°
Day/Night	Auto (ICR) / Manual
Shutter Speed	PAL: 1/25~1/100000s
Min.Illumination	0.05Lux/F2.0, 0Lux IR on
IR	Up to 20m (66feet)
S/N	More than 65dB
WDR	DWDR
AWB(Auto White Balance)	Auto / Manual
Digital Zoom	16x
Noise Reduction	2D
Video
Frame Rate	25/30fps@960P
HLC	Supported
BLC	Supported
OSD	Multi-language
Interface
Video Output	1-channel BNC high definition video output / CVBS video output (Can switch)
Function
Storage Conditions	-40°C~+60°C (-40°F~+140°F)/ Lessthan90%RH
General
Power	12V DC±25%
Power Consumption	Max 2.8W (12V DC, IR on)
Working Temperature	-40°C~+60°C (-40°F~+140°F)
Working Humidity	Less than 90%RH
Dimension	Φ85.4mm × 69.1mm (Φ3.36″×2.72″)
Weight	0.11kg (0.24lb)
