Description
| Camera | |
|---|---|
| Image Sensor | 1/ 2.8” CMOS |
| Lens | 2.8mm, horizontal field of view: 107°/ 3.6mm, horizontal field of view: 86.6°/ 6mm, horizontal field of view: 56° (optional)* |
| Angle of View (H) | 107° |
| Shutter Speed | Auto |
| Min.Illumination | 0 lux (LED ON) |
| IR | 20m |
| S/N | ≥52dB (AGC OFF) |
| WDR | Digital WDR |
| AWB(Auto White Balance) | Yes |
| Digital Zoom | 16x |
| Noise Reduction | 2D DNR |
| Video | |
| Frame Rate | 30fps (60Hz); 25fps (50Hz) |
| HLC | Supported |
| BLC | Supported |
| OSD | OSD (COC Control) |
| Audio | |
| Audio Compression | G711 |
| Smart Features | |
| Image Settings | Yes |
| Interface | |
| Video Output | AHD/TVI/CVI/CVBS |
| Built-in Mic | 1CH built-in MIC |
| General | |
| Power | DC 12V (± 15%) |
| Power Consumption | LED Off : 1W ; LED On : 3W |
| Working Temperature | -30°C ~ 50° C |
| Working Humidity | 10% ~ 90% (relative humidity) |
| Ingress Protection | IP67 |
| Dimension | 162.1× 74.8× 73.8 |
| Weight | Approx. 0.37KG |
