Name: MC-SGFI24-300W
SKU: 1973
Availability: InStock

MC-SGFI24-300W

( 0 out of 5 )

₹100.00

8 PORT AI PoE SWITCH

Product Features

Using CAT.5 network patch cords support power for the wireless AP/CPE and IP camera/PTZ
Networking standard: IEEE802.3af/at/bt
POE power light blinks to determine the power status of the receiving end, and each blink is 2.7 watts.
PoE Watchdog AI Function: Detection front-end PoE cameras and PD, Automatic detection, Automatic restart
Support 60W PoE receiving power, free of power adapter & simplify power supply
6KV lightning protection, 8KV surge protection, anti-reverse connection, over-current protection, over-voltage protection, over-temperature protection, Short circuit protection
The Max output power of the port is 60W, which is convenient for hi-power equipment
Zero configuration feature power supply is automatically supplied to the adaptive equipment

Category: CCTV

Description

PoE Switches
Network Port	11000Mbps SFP Port+21000Mbps Uplink ports +21000Mbps PoE port(Compatible uplink) + 6100Mbps PoE ports
Transfer Rate	2000Mbps Full Duplex; 10 or 100 or 1000Mbps Half Duplex
Performance	Bandwidth: 11.2Gbps ; Network Latency (10 to 1000Mbps): ≦16μs (use the 64byte package size) ; MAC address table: 8K ; The Frame Filter & Transmission Rate: 14800pps the most for 10M port, 148800pps the most for 100M port,1488000pps the most for 1000M port
Network protocol and standard	IEEE 802.3i 10BASE-T IEEE 802.3u 100BASE-TX/ IEEE 802.3ab 1000BASE-T IEEE 802.3xFlowControl IEEE 802.3af/at/bt Power over Ethernet
Power	Power input: AC 110~220V Total ≤120W ; PoE Watchdog: Port 1-8 ; Power output: PoE1~6Port:1/2(+52V),3/6(GND)≤30W PoE7~8Port:1245(+53V),3678(GND) compatible1/2(+52V),3/6(GND)≤60W
Input Voltage Range	AC 110~220V Total ≤120W
